Precision Double-Sided Dust Remover

What it does

Takes off the dust and burrs that cause most rejected top coats — both faces, one pass.

Dust on the board is the most common cause of rejected top coats. This machine runs four rollers over both faces of the workpiece and pulls debris into a centralised exhaust.

Conveying speed is adjustable to match the line, making it the standard prep stage before curtain or roller top-coat machines.

Key features

• Burr & chip cleaningRemoves burrs and wood chips from all wooden workpieces before coating.
• Double-sided four rollersCleans both faces in one pass with adjustable conveying speed.
• Centralised exhaustIntegrated exhaust system captures dust for a more ideal removal effect.

Applications

At a glance

Working width	1300 mm
Workpiece thickness	10–50 mm
Roller power	2.2–3 kW ×4
Min. working length	500 mm

Ask about this machine

Tell us the material, panel size and target output and we will confirm the right model, working width and line position — and whether a different station suits you better.
